North America Nebula in Different Lights
Ssc2011 03a3

Credit: NASA/JPL-Caltech/L. Rebull (SSC/Caltech)/D. De Martin

Observation • February 10th, 2011 • ssc2011-03a3

ssc2011-03a3

This new view of the North America nebula combines both visible and infrared light observations, taken by the Digitized Sky Survey and NASA's Spitzer Space Telescope, respectively, into a single vivid picture.

The nebula is named after its resemblance to the North America content in visible light, which in this image is represented in blue hues. Infrared light, displayed here in red and green, can penetrate deep into the dust, revealing multitudes of hidden stars and dusty clouds. Only the very densest dust clouds remain opaque, like the dark bands seen in the "Gulf of Mexico" area.

Clusters of young stars (about one million years old) can be found throughout the image. Slightly older but still very young stars (about three to five million years) are also liberally scattered across the complex, with concentrations near the "head" region of the Pelican nebula, which is located to the right of the North America nebula (upper right, bluish portion of this picture).

In this combined view, the visible part of the spectrum from the Digitized Sky Survey is represented in blues and blue-green hues. The Spitzer component contains data from the infrared array camera. Light with a wavelength of 3.6 microns has been color-coded green; 4.5-micron light is orange; 5.8-micron and 8.0-micron light are red.

About the Object

Name
North America NebulaNGC 7000Pelican NebulaIC 5070IC 5067
Type
Star > Evolutionary Stage > Protostar
Nebula > Appearance > Emission
Nebula > Appearance > Dark
Star > Evolutionary Stage > Protostar
Distance
2,000 Light Years

Color Mapping

Band Wavelength Telescope
Optical 440 nm DSS
Optical 700 nm DSS
Infrared 3.6 µm Spitzer IRAC
Infrared 4.5 µm Spitzer IRAC
Infrared 5.8 µm Spitzer IRAC
Infrared 8.0 µm Spitzer IRAC

Astrometrics

Position (J2000)
RA =2h 56m 31.4s
Dec = 44° 7' 50.9"
Field of View
2.3 x 2.3 degrees
Orientation
North is 356.4° left of vertical
