Baby Picture of our Solar System: The Spinning Top Star in Infrared
Ssc2007 19b

Credit: NASA/JPL-Caltech/UIUC, Caltech/SSC

Observation • November 29th, 2007 • ssc2007-19a1

ssc2007-19a1

A rare, infrared view of a developing star and its flaring jets taken by NASA's Spitzer Space Telescope shows us what our own solar system might have looked like billions of years ago. In visible light, this star and its surrounding regions are completely hidden in darkness.

Stars form out of spinning clouds, or envelopes, of gas and dust. As the envelopes flatten and collapse, jets of gas stream outward and a swirling disk of planet-forming material takes shape around the forming star. Eventually, the envelope and jets disappear, leaving a newborn star with a suite of planets. This process takes millions of years.

The Spitzer image shows a developing sun-like star, called L1157, that is only thousands of years old (for comparison, our solar system is around 4.5 billion years old). Why is the young system only visible in infrared light? The answer has to do with the fact that stars are born in the darkest and dustiest corners of space, where little visible light can escape. But the heat, or infrared light, of an object can be detected through the dust.

In Spitzer's infrared view of L1157, the star itself is hidden but its envelope is visible in silhouette as a thick black bar. While Spitzer can peer through this region's dust, it cannot penetrate the envelope itself. Hence, the envelope appears black. The thickest part of the envelope can be seen as the black line crossing the giant jets. This L1157 portrait provides the first clear look at stellar envelope that has begun to flatten.

The color white shows the hottest parts of the jets, with temperatures around 100 degrees Celsius (212 degrees Fahrenheit). Most of the material in the jets, seen in orange, is roughly zero degrees on the Celsius and Fahrenheit scales.

The reddish haze all around the picture is dust. The white dots are other stars, mostly in the background.

L1157 is located 800 light-years away in the constellation Cepheus.

About the Object

Name
L1157
Type
Star > Evolutionary Stage > Protostar
Nebula > Type > Jet
Nebula > Type > Star Formation
Nebula > Appearance > Dark
Star > Circumstellar Material > Outflow
Distance
815 Light Years

Color Mapping

Band Wavelength Telescope
Infrared 3.6 µm Spitzer IRAC
Infrared 4.5 µm Spitzer IRAC
Infrared 8.0 µm Spitzer IRAC

Astrometrics

Position (J2000)
RA =20h 39m 6.1s
Dec = 68° 2' 16.0"
Field of View
17.5 x 21.6 arcminutes
Orientation
North is 354.8° left of vertical
