Pools of Dust Around Exploded Star
Sig14 014

Credit: NASA/JPL-Caltech/Goddard

Observation • June 4th, 2014 • sig14-014


This infrared image from NASA's Spitzer Space Telescope shows a close-up of N103B -- all that remains from a supernova that exploded a millennium ago in the Large Magellanic Cloud, a satellite galaxy of the Milky Way 160,000 light years away.

Spitzer's instruments pick up infrared light emitted by dust in both the remnant and the surrounding interstellar medium. The infrared light has been translated to colors we see in this image, allowing astronomers to dissect the scene. In this image, dust associated with the remnant appears red, while dust in the ambient background of the galaxy appears yellow and green. Stars in the field appear blue.

By studying the infrared light emitted from this supernova remnant, astronomers have determined that the density of the gas surrounding the supernova is much higher than is typical for a 'Type Ia' supernova, which are those that occur when dead stars called white dwarfs explode. Astronomers believe that this dense material was expelled prior to the supernova explosion, possibly by a companion to the white dwarf -- an aging star that shed the material.

Most Type Ia supernovas do not show evidence for this process occurring, making N103B an example of a rare subclass of Type Ia explosions. In fact, only one other remnant of a Type Ia explosion shows evidence for this: the remnant of Kepler's supernova in our own galaxy, the remains of the explosion of a star witnessed on Earth in 1604 A.D.

The red data shows infrared light with wavelengths of 16 and 24 microns, while shorter-wavelength infrared light of 3.6, 4.5, and 8 microns is shown as blue, cyan and green, respectively.

About the Object

Nebula > Type > Supernova Remnant

Color Mapping

Band Wavelength Telescope
Infrared 3.6 µm Spitzer IRAC
Infrared 4.5 µm Spitzer IRAC
Infrared 8.0 µm Spitzer IRAC
Infrared 16.0 µm Spitzer IRS
Infrared 24.0 µm Spitzer MIPS


Position ()
RA =5h 8m 58.6s
Dec = -68° 43' 34.2"
Field of View
1.9 x 1.9 arcminutes
North is 1.7° right of vertical
